Valve 2-5 Valve Model Description Distribution Flow Pathway 2-portsFluid Pathway PTFE|CTFE Valve Size HVXM Nominal Port Diameter 0.118 inch (3 mm) Valve Outer Body Dimension 1 inch (25.4 mm) Housing Material Aluminum Total Dead Volume 108.8 uL Actuated ModuLar Valve Positioner Break Away Torque 65 in oz. (455 mNm) Initial Break Away Torque 100 in oz (706 mNm) Panel Mounting No Threa

The Hamilton 2-5 Valve features a distribution flow pathway with 2 ports and a fluid pathway made of PTFE|CTFE. The valve's size is HVXM with a nominal port diameter of 0.118 inches (3 mm) and an outer body dimension of 1 inch (25.4 mm). It is constructed with an aluminum housing material and has a total dead volume of 108.8 uL.

This valve is equipped with an actuated modular valve positioner, offering a breakaway torque of 65 in oz. (455 mNm) and an initial breakaway torque of 100 in oz (706 mNm). The valve does not support panel mounting and does not come with thread compatibility.

Designed for precise fluid control and distribution, the Hamilton 2-5 Valve is a reliable choice for laboratory applications that require accurate and efficient valve functionality.
